InterOp:Graphical/STEP Graphical

From DocR23

Jump to: navigation, search



Contents

 GRAPHIC Part1.png

Supported Graphical Data

Graphical Data
Graphical PMI Graphical Geometry
PMI Solid Surface Wire Point
GRAPHIC checkmark.png GRAPHIC checkmark.png GRAPHIC checkmark.png

Supported Formats

Refer to Format and Version Support for a list of supported STEP versions.

Graphical Data

Graphical data in 3D InterOp Graphical for STEP is generated from the imported B-rep model.

Graphical Geometry

The InterOp STEP Graphical reader provides graphical data for Solids, Sheets, and Wires. Graphical data for STEP is provided by first importing STEP geometry and tessellating the imported B-rep.

Limitations

The InterOp STEP Graphical Reader has the following limitations:

  • Does not support graphical PMI
  • Does not support free points
